PRODUCT SCENE VISUALIZATION Back to industrial systemsHIGH PAYLOAD / LONG ENDURANCETF100
Six-Rotor High-Payload UAV
A six-rotor carbon-fiber platform with up to 50 kg payload capacity and multi-constellation positioning.
- Maximum payload
- 50 kg
- No-load endurance
- 70 min
- 50 kg endurance
- 25 min
- Max. speed
- 20 m/s
Request product details More models and documents available by inquiry
01 / PRODUCT OVERVIEW
Made for a clearly defined use case.
TF100 combines high payload capacity with a folding industrial airframe. It is intended for project discussions where load, range, endurance and payload interface need to be evaluated together.
02 / SPECIFICATIONS
Technical data
Based on the product material supplied for this website. Final configuration is confirmed for each inquiry.
- Material
- High-strength carbon fiber
- Rotor configuration
- 6-axis / 6-propeller
- Propeller
- 41-inch folding propeller
- Expanded size
- 2430 × 2140 × 350 mm
- Folded size
- 860 × 1170 × 350 mm
- Wheelbase
- 2200 mm
- Aircraft weight
- 25 kg
- Battery
- 6.3 kg × 4
- Maximum payload
- 50 kg
- Maximum takeoff weight
- 104 kg
- No-load endurance
- 70 min
- Endurance with 50 kg payload
- 25 min
- Maximum flight speed
- 20 m/s
- Positioning
- GPS / BeiDou / Galileo / GLONASS
- Positioning accuracy
- ±0.5 m
03 / BUYER FIT
Built for organizations that buy with a defined purpose.
Who this model may fit
- Civilian heavy-payload project integrators
- Industrial logistics and equipment teams
- Buyers evaluating a 50 kg payload class
What to include in your inquiry
- Required payload and flight profile
- Range, altitude and environmental conditions
- Trial or batch quantity and destination
CONFIGURATION & DOCUMENTATION
Prepare an inquiry
